Cables and New Energy Products / Connectors
HPL36 series connectors with high-voltage interlock
Model:
1 / 11
1
2
3
4
5
6
7
8
9
10
11
Description
This product is a metal-shell connector with a compact size, offering better shielding performance than plastic-shell products. Its 2-core, 3-core, and 4-core compact designs are better suited for applications in narrow spaces. The HPL36 series connector is a solution developed for low- and medium-current applications in new energy vehicles. It is mainly used in equipment such as PDU, air conditioning, PTC, DC/DC, oil pumps, air pumps, defrosting, and slow charging.
Features
- This product is a metal-shell connector with a compact size, and its shielding effect is superior to plastic-shell products. The 2-core, 3-core, and 4-core compact designs of this product can better adapt to applications in narrow spaces. The HPL36 series connector is a solution developed for small and medium current applications in new energy vehicles. It is mainly used in equipment such as PDU, air conditioning, PTC, DC/DC, oil pump, air pump, defrosting, and slow charging.
Specifications
00-插座 6-插头
1HPL36-04*-41-2.5 / 插座/ 4芯/高压互锁 / 2.5mm²非屏蔽线
2芯数：2-两芯
3芯数： 3-三芯 4-四芯
42.5-适配线径2.5mm² 4-适配线径4mm² 6-适配线径6mm²
5HPL36-64*-41-2.5 / 插头/ 4芯/高压互锁 / 4mm²屏蔽线
6HPL36-64*-41-4 / 插头/ 4芯/高压互锁 / 6mm²屏蔽线
7HPL36-04*-40-6 / 插座/ 4芯/无高压互锁 / 2.5mm²非屏蔽线
8HPL36-04*-40-10 / 插座/ 4芯/无高压互锁 / 4mm²非屏蔽线
