Eco-friendly PVC Bonding Dual Wall Tubing - WoEr+ Technology

Back to Products

Products/Electronic series products/Double-arm rubberized heat-shrinkable tube

Electronic series products / Double-arm rubberized heat-shrinkable tube

Eco-friendly PVC Bonding Dual Wall Tubing

Model: SBRS-(3X)GVC

Eco-friendly PVC Bonding Dual Wall Tubing

1 / 3

Eco-friendly PVC Bonding Dual Wall Tubing 1

1

Eco-friendly PVC Bonding Dual Wall Tubing 2

2

Eco-friendly PVC Bonding Dual Wall Tubing 3

3

Description

Applications

Wiring harnesses, marine cables, metal pipes requiring waterproof

Description

SBRS-(3X)GVC PVC bonding dual wall tubing. Excellent adhesion to PVC and metals. UL certified, outer FR UV resistant. 3:1, RoHS, -45℃~125℃.

Features

Eco-friendly: RoHS
Excellent adhesion to PVC and metals

Previous Product3:1 Halogen-Free FR Dual Wall Heat Shrink Tubing

Next Product3:1 Soft Thick Adhesive Low Temp Dual Wall Tubing

Dual function: insulation + waterproof

Wide temp: -45℃~125℃

Self-extinguishing FR

UL Certified

Shrink Ratio: 3:1

Color: Black

Specifications

FRSelf-extinguish 30s

ColorBlack(custom OK)

Tensile≥10.4 MPa

Peel(Al)≥120N/25mm

Peel(PE)≥90N/25mm

Oper Temp-45℃~+125℃

Dielectric≥15kV/mm

Elongation≥300%

Full Shrink≥+125℃

Init Shrink≥+70℃

Resistivity≥10¹⁴ Ω·cm

Aged Tensile≥7.3MPa(158℃×168h)

Shrink Ratio3:1

UL CertifiedYes

EnvironmentalRoHS

Adhesive Softening90±5℃

Similar Products

3:1 & 4:1 Military Standard High FR Dual Wall Tubing

3:1 & 4:1 Military Standard High FR Dual Wall Tubing

Model: SBRS-(3X,4X)GFF

3:1 & 4:1 Military Standard Dual Wall Heat Shrink Tubing

3:1 & 4:1 Military Standard Dual Wall Heat Shrink Tubing

Model: SBRS-(3X,4X)GF

3:1 & 4:1 Eco-friendly Dual Wall Heat Shrink Tubing

3:1 & 4:1 Eco-friendly Dual Wall Heat Shrink Tubing

Model: SBRS-(3X,4X)G

Eco-friendly PVC Bonding Dual Wall Tubing

1 / 3

Eco-friendly PVC Bonding Dual Wall Tubing 1

1

Eco-friendly PVC Bonding Dual Wall Tubing 2

2

Eco-friendly PVC Bonding Dual Wall Tubing 3

3

Features

Eco-friendly: RoHS
Excellent adhesion to PVC and metals
Dual function: insulation + waterproof
Wide temp: -45℃~125℃
Self-extinguishing FR
UL Certified
Shrink Ratio: 3:1
Color: Black

Specifications

FRSelf-extinguish 30s

ColorBlack(custom OK)

Tensile≥10.4 MPa

Peel(Al)≥120N/25mm

Peel(PE)≥90N/25mm

Oper Temp-45℃~+125℃

Dielectric≥15kV/mm

Elongation≥300%

Full Shrink≥+125℃

Init Shrink≥+70℃

Resistivity≥10¹⁴ Ω·cm

Aged Tensile≥7.3MPa(158℃×168h)

Similar Products

3:1 & 4:1 Military Standard High FR Dual Wall Tubing

3:1 & 4:1 Military Standard High FR Dual Wall Tubing

Model: SBRS-(3X,4X)GFF

3:1 & 4:1 Military Standard Dual Wall Heat Shrink Tubing

3:1 & 4:1 Military Standard Dual Wall Heat Shrink Tubing

Model: SBRS-(3X,4X)GF

3:1 & 4:1 Eco-friendly Dual Wall Heat Shrink Tubing

3:1 & 4:1 Eco-friendly Dual Wall Heat Shrink Tubing

Electronic series products / Double-arm rubberized heat-shrinkable tube

Eco-friendly PVC Bonding Dual Wall Tubing

Model: SBRS-(3X)GVC

Description

Applications

Wiring harnesses, marine cables, metal pipes requiring waterproof

Description

SBRS-(3X)GVC PVC bonding dual wall tubing. Excellent adhesion to PVC and metals. UL certified, outer FR UV resistant. 3:1, RoHS, -45℃~125℃.

Shrink Ratio

3:1

UL CertifiedYes

EnvironmentalRoHS

Adhesive Softening90±5℃

Model: SBRS-(3X,4X)G
