1HV280L02*H02 / Socket * keyed with high-voltage interlock socket / 2.5mm² unshielded cable
2HV280L02*H04 / Socket * keyed with high-voltage interlock socket / 4.0mm² unshielded cable
3HV280L062*H06 / Socket * keyed with high-voltage interlock socket / 6.0mm² unshielded cable
4HV280L02*N02 / Socket * keyed without high-voltage interlock socket / 2.5mm² unshielded cable
5HV280L02*N04 / Socket * keyed without high-voltage interlock socket / 4.0mm² unshielded cable
6HV280L02*N06 / Socket * keyed without high-voltage interlock socket / 6.0mm² unshielded cable
7HV280L03*H02 / Socket * keyed with high-voltage interlock socket / 2.5mm² unshielded cable
8HV280L03*H04 / Socket * keyed with high-voltage interlock socket / 4.0mm² unshielded cable
9HV280L03*H06 / Socket * keyed with high-voltage interlock socket / 6.0mm² unshielded cable
10HV280L03*N02 / Socket * keyed without high-voltage interlock socket / 2.5mm² unshielded cable
11HV280L03*N04 / Socket * keyed without high-voltage interlock socket / 4.0mm² unshielded cable
12HV280L03*N06 / Socket * keyed without high-voltage interlock socket / 6.0mm² unshielded cable
6262-two-core plug 63-three-core plug 02-two-core socket 03-three-core socket
No.Ordering Part Number / Product Description / Compatible Cable Specification
Selection SeriesHV280L
AKey position: A, B, D, E
HHigh-voltage interlock: H - with high-voltage interlock, N - without high-voltage interlock
02Wiring specification: 02 - 2.5mm², 04 - 4.0mm², 06 - 6.0mm²
